16 January '14 by Brian Klipfel, under Fire Works Masonry News.
Our latest project is an energy efficient, wood burning, masonry fireplace in Jim Thorpe, PA. The fireplace has a heated limestone bench, mantel, and capping stones. A natural thin veneer stone will face the simple block shell. A small curing fire warms the home for the first time in the photo below.
At the heart of the fireplace is the high temperature double bell core. The hand-built firebrick core is completed in the photo below.
The photo below shows the completed core. The core is ready for the block/brick facing.
Fire Works Masonry
29 December '13 by Brian Klipfel, under Fire Works Masonry News.
Fire Works Masonry recently completed the installation of the heart of an energy efficient fireplace in Hacketsttown, NJ. The photos below show the completed firebrick core for a clean burning Finnish contraflow masonry heater core. This fireplace has a “white” bake-oven, two heated benches and an offset chimney to the left of the firebox.
The firebrick core will be faced will locally sourced field-stones.
This masonry stove warms and divides the kitchen, on the bake-oven side, and the family dining room.
Check back for updates after the stone facing is completed.
Fire Works Masonry
11 August '13 by Brian Klipfel, under Fire Works Masonry News.
Fire Works Masonry’s latest job was an outstanding opportunity to build a masonry stove for our friend and Masonry Heater Association colleague Aki Yoshimizu in his lake cottage in Nagano, Japan. Aki is a builder in Japan and is the owner of Peak Home Builders. The photo below shows the functioning, almost complete heater.
The heater was designed by and built with MHA founding member Norbert Senf of Masonry Stove Builders from Quebec, Canada. Norbert also posted a detailed photo report of the entire project on the MHA News E-zine.
The energy efficient fireplace is a Finnish contraflow core based on the Masonry Heater Association’s Heater Plan Portfolio. The fireplace is faced with dense brick pavers. The rough stucco coat will be finished in a local Japanese clay plaster. The photo below shows the first small curing fire burning in the firebox.
The lakeside cottage is located in a beautiful rural setting. Like many homes in Japan, the home is not well insulated and can be a challenge to heat in the winter. The mountainous area regularly gets heavy snow falls and temperatures as low as 0F. Aki became interested in the possibilities to heat efficiently and cleanly with locally available firewood.
The photo below shows the great view of the quiet lake from our workroom door.
The heater starts with the layout. The masonry stove will have a very unique heat exchanger design for the upper bedrooms designed by Norbert.
Once we establish the layout, the base courses of the fireplace begin. The photo below shows a new layout design for the contraflow base designed by MHA member Eric Moshier.
Aki hosted the build as a workshop and several interested and adept volunteers attended. The photo below shows Norbert Senf, Mamoro Ooishi, Yuuichi Kada, and Takeo Onozawa.
Mamoro is a chimney sweep and woodstove salesman from Hokkaidou. Yuuichi is a mason and garden craftsworker
from Aichi, about four hours away, and Takeo (Ono) is a chimney sweep from Nagano. They met while doing volunteer
work after the Tsunami.
With so many helping hands, the build goes quickly. The photo below shows the completed firebox and the start of the throat behind the white oven.
The white oven slabs are installed. Aki is a carpenter and builder. He made excellent forms and castings for the high temperature concrete slabs.
The final courses and secondary combustion chamber are completed above the bake-oven.
The two side downdraft channels can be built next.
Once the side channels are complete the crew installs the heavy high temperature capping slabs.
With the core completed, the crew enjoyed a great evening campfire and cookout.
The masonry stove work begins again the next morning. Locally available dense, red brick pavers will face the core.
The bricks are delivered to the jobsite. The local hardware store allows customers to borrow this small pickup for 90 minutes with no charge. These useful small pick-up trucks are everywhere in Japan. The truck gets about 50mpg, carries over 700lbs and costs under $9,000.
The photo below shows the start of the face brick, chimney connection, and small heated bench.
The heater installation is in a seismic zone. Threaded rods are drilled and epoxied into the base concrete slab. The rods will be buried in the mortar slush between the core and facing. A steel plate on top of the heater will bond the masonry and rods together.
The brick facing is about halfway complete after a long day. The jack arch spanning the door openings is the next step.
Norbert inserts the keystone into the jack-arch. The jack-arch is left proud from the brick facing for a design element.
The brick facing progresses. The photo below shows the closing keystone for the second jack-arch above the bake-oven door.
Norbert’s heater design also includes a unique curved brick wall surrounding the chimney connection. The curved section is seen in the photo below.
The final brick courses are nearly complete in the photo below. One of the threaded rods for the seismic reinforcing can be seen above the brick to the right.
With the brickwork completed, the stucco plaster coat begins. Aki looks admiringly at the brick face while he holds a fiberglass mesh in place to reinforce the plaster facing.
Later that evening the crew burns the first small curing fire around the completed rough coat heater.
With the rough plaster coat completed, the doors are installed into the brick facing.
The photo below shows the nearly completed, clean burning, energy efficient fireplace with another small curing fire. The heater still needs the final plate for the seismic reinforcement, a small top for the heated bench, and a final decorative plaster coating. Aki will most likely use a local, traditional clay or lime plaster.
Fire Works Masonry
31 July '13 by Brian Klipfel, under Fire Works Masonry News.
Fire Works Masonry latest commercial wood fired oven is a large 48″ x 72″ vaulted brick oven for the Hearthstone Grill in Jamesburg, NJ. The oven will be used for a variety of foods including pizzas, cast iron dishes, roasted meats and vegetables as well as fresh in-house breads. The large oven and newly renovated restaurant are seen in the photo below.
The oven starts with the firebrick core. The oven was designed by MHA founding member Tom Trout of Vespa Masonry. The photo below shows a view through the loading door into the newly built brick oven. The oven’s firebrick floor is also ready to start cooking. The rough chimney connection is visible in the far back left hand corner.
A strong steel frame permanently supports the outer thrust of the long vaulted span. The completed oven core and steel support structure are pictured below.
The photo below shows the top of the oven vault. This oven will be heavily insulated with commercial, high temperature thermal blankets.
The oven facing will be based on steel studs with cement board after the thick insulation for the sides and top. The front of the oven is faced in an additional layer of firebrick. This oven facing can be nicely completed with many options such as thin veneer stone, tile, mosaics, or plaster stucco to match any interior.
The owner and his crew will complete this oven exterior with a cultured stone and tile veneer.
The photo below shows the completed oven core, front brick face and the steel stud frame underway.
After hours of heat storage, the oven heats up to operating temperatures for cooking pizzas in minutes. The photo below shows the vault burning clean.
The oven has a custom insulated stainless steel door for use between shifts or overnight to maintain the oven’s heat.
The door fits tightly into the vaulted opening for loading the oven. The owner’s custom stained glass and cultured stone finish is also completed.
Fire Works Masonry
05 May '13 by Brian Klipfel, under Fire Works Masonry News.
Fire Works Masonry’s latest clients are building a low energy home in Pennsylvania’s Lehigh Valley. While researching energy efficient fireplaces, they discovered the clean burning masonry stove. They contacted Fire Works Masonry for a custom, field stone faced masonry heater. The fireplace is a double bell layout, designed for great efficiency.
One of the first curing fires burns in the firebox in the photo below.
The masonry heater has a wood-box to the left of the firebox and and heated bench to the right. The optional bake-oven sits directly above the firebox.
The wood-box, heated bench, and oven shelf are all shaped from colorful slabs of Tennessee sandstone.
Fire Work Masonry
18 February '13 by Brian Klipfel, under Fire Works Masonry News.
Our latest project is a hand-built, custom 60″ dome brick wood-fired oven. You can find the new restaurant, Johnny’s Wood-Oven Pizzeria, in Chadd’s Ford just outside Philadelphia, PA. The photo below shows the completed oven. The oven exterior is a tile mosaic with a brick base finished by the owner.
The oven is the focal point of the new restaurant, directly behind the bar counter. The photo below shows the view directly through the front entrance.
Once the masonry block base and concrete hearth slab are complete the oven begins. The oven floor and walls are built on top of 4″ of load bearing, commercial grade insulation. The photo below shows the firebrick floor and walls underway. The first course of the form free dome construction has begun.
The dome is built entirely of high duty firebrick. Every brick is cut to achieve tight, long lasting joints. The dome is about halfway complete in the photo below.
The arched door opening in the dome is shown below.
Once the dome is complete, 4″ of commercial ceramic wool insulation covers the oven.
The insulation is covered with a rough stucco coat. The oven is now ready for any type of final facing.
The owner, John, finished the oven in a combination of brick, tile mosaic, and stucco. He’s working the new oven in the photo below.
One of the first hot fires rolls over the dome in the photo below. Notice how clean the oven ceiling is, indicating a hot clean fire burning in the oven.
One a the oven’s first pizzas after just a few seconds in the hot oven cooks on the firebrick floor in the photo below.
In about a minute, the pizza is out and ready to eat.
Fire Works Masonry
15 December '12 by Brian Klipfel, under Fire Works Masonry News.
Our latest project is a Finnish Contraflow masonry stove in Delaware County, PA. Our clients were building a unique addition onto their existing home. The large masonry heater is both the primary heat as well as the visual focal point for the new space. The owner’s designed the heater inspired by our King of Prussia masonry heater installation. The fireplace has long sandstone heated benches, stone mantel and shelves, a white bake-oven, and a large wood-box for wood storage.
The fireplace starts with the high temperature core. The core is made entirely of firebricks bonded with high temperature mortar. The photo below shows the nearly complete core and the heated bench firebrick lining channels under construction. The combustion exhaust gases exit through the chimney to the far right of the firebox.
Once the core is completed, it is faced with masonry blocks.
After the block shell is completed, the colorful sandstone benches and accent pieces are set.
The entire heater is plastered with several coats of stucco. The first small curing fire burns in the photo below.
The photo below shows some detail of the colorful sandstone bench tops.
The heater has a large wood-box to store the week’s firewood.
Fire Works Masonry
20 November '12 by Brian Klipfel, under Fire Works Masonry News.
Our latest project is a large backyard wood-fired oven. The hand-built dome oven is constructed entirely of long lasting, high duty firebricks. The oven floor has a 36″ diameter, plenty of room for a large pizza party or an entire Thanksgiving meal. The photo below shows one of the first hot fires rolling over the top of the oven as it heats the firebrick dome.
The tight brickwork is built form free. The every brick is cut to ensure very tight, strong joints. High temperature refractory mortar provides the joint strength between the bricks. The high quality of the firebricks and construction method assure a very functional, long lasting oven. A well made oven lasts for generations. The photograph below shows the dome nearly halfway complete.
The high mass of the oven works great for cooking but requires a masonry foundation to carry the load. A block foundation supports this oven. The oven is insulated from the foundation by 4″ of industrial, load bearing insulation. The dome continues to roll in as the door opening begins below.
The photo below shows the completed wood-fired oven core. The door opening and chimney throat can be seen on the right hand side of the core in the photo below.
The photo below shot through the door opening shows the completed dome from inside the oven. The smooth firebrick floor is also ready to start cooking.
With the core completed, the oven facing can begin. A simple block shell will be constructed around the core. The firebrick core will also be wrapped in 4″ of industrial quality ceramic wool blanket. This helps lock in the oven’s heat for long lasting, efficient cooking.
Finally the oven is fired and the first pizza sizzles on the hot floor.
Once the pizza party is over, the very versatile oven is ready for almost any type of food you can imagine. The oven can roast meats and vegetables as well as bake excellent breads. Fresh pita breads expand on the hearth in the photo below.
You can perfectly roast meats as well, such as the tender oven roasted chicken in the photo below.
Oven roasted garlic is another favorite.
Garden tomatoes are roasting in the photo below before they are sauced and canned.
Cast iron cookware gets great results in the oven. A cast iron skillet roasts garden garlic and asparagus in the photo below.
Fire Works Masonry
18 November '12 by Brian Klipfel, under Fire Works Masonry News.
When our clients in Reading, Pennsylvania planned their energy efficient addition to their home, a masonry stove was in the center of their plans. A clean burning masonry heater replaced a drafty, traditional masonry fireplace. The masonry heater sits between the existing living room and new addition, diving the man living space. Their kids stand safely on the heated bench in the photo below as their project nears completion.
At the heart of the masonry heater is the double bell core. It stands completed in the photo below. The masonry heater has a see-thru firebox and heated benches.
The masonry heater core is faced with masonry blocks, filled solid for heat transfer and storage.
The new addition side of the fireplace has an extended heated bench, a long stone mantle and a panoramic door for viewing the fire.
The living room side of the see-thru masonry heater will also have a heated bench as well as a bake-oven above the loading door.
Once the masonry block shell is completed around the core, the natural thin veneer stone facing begins.
The Pennsylvania fieldstone facing is finished and grouted. The photo below shows the completed fireplace warming the nearly finished new addition.
The heater is complete and warming the new addition.
Fire Works Masonry
19 July '12 by Brian Klipfel, under Fire Works Masonry News.
Our most recent project is a double bell masonry heater installation in scenic Galax, Va. The owners of this new project in the rolling Blue Ridge Mountains were determined to build an efficient home. They decided on a masonry heater for the heart of the design. With no local masons certified in heater building, the owners reached out to Fire Works Masonry. The picture below shows a small curing fire in the nearly complete fireplace.
The double bell masonry stove was sized and designed for the new home. The design includes a spacious firebox and a black-oven for cooking. The completed core is pictured below.
The photo below shows a view of the core during the construction process. The black bake-oven has been completed and is ready to be capped. A temporary form supports the freshly laid arch bricks over the oven door opening. The up and down-draft heat exchange channels are also visible.
The second, or double, bell is then completed above the oven.
Once the core is completed the brick facing began. The photos below show the nearly completed brickwork. A small curing fire begins to dry the new fireplace.
